This hydraulic roll groover equips with updated hydraulic pump, with convenient depth adjusting function, powered by 750w induction motor, is capable of grooving 1''-6'' pipes. Separate knurling roller design of drive shaft for convenient replacement.

● This Machine is designed for grooving 1"-6"
● Simple design of the carriage, easy to be assembled and transported
● Equipped with integral hydraulic pump and stroke limitation device to control the depth of grooves precisely and effectively.

Specifications
Model: STG6A
Capacity: 1"-6"(33-168mm diameter)SCH40 steel pipe
1"-6"(33-168mm diameter)SCH10S SCH5S SCH10 SCH5 thin wall steel pipe
Max. wall thickness: 6mm
Motor power: 750W
Output RPM: 23rpm

G.W.:96kgs
Packaging size: 95x53x65cm

Standard Equipment
* For SCH40 steel pipe
Knurl wheel φ33-φ48
Knurl wheel φ57-φ89
Knurl wheel φ108-φ168
Pinch Roller φ33-φ48
Pinch Roller φ57-φ168

Optimal Equipment*For SCH10S SCH5S SCH10 SCH5 thin wall steel pipe
Thin wall knurl wheel φ33-φ48
Thin wall knurl wheel φ57-φ89
Thin wall knurl wheel φ108-φ168

PICTURES FOR ROLL GROOVER MACHINE 1''-6''

1) Simple design of the carriage, easy to be assembled and transported
2) Equipped with integral hydraulic pump and stroke limitation device to control the depth of grooves precisely and effectively

Roll grooving machine is a kind of pipe tool for workers to make groove then connect pipe by using grooved joints such as couplings.
The principle of grooving machine is hard extrusion, when the upper roller touches the pipe surface, turn on the motor, handle the hydraulic oil pump to make the pipe rotate. The upper roller can press the pipe by shaking the handle of hydraulic oil pump, then form a groove. Roll grooving machine is widely used in fire-fighting system, Sprinkler systems, installations, larger heading units, industrial use and mining. The grooving machine is characterized by compact structure, flexible operation and beautiful shape.

FAQ

1. WHO ARE WE?
We are professional pipe machine manufacturer located in Hangzhou city of China starts from 1989, we are close to Port Shanghai, Ningbo as well as Yiwu. We mainly export to North and South America, South Asia and the Middle East countries. Our client are power tools wholesaler and comnpany for specific constrution project such as fire fighting pipeline building etc.
2. HOW CAN WE GUARANTEE THE QUALITY?
We always test at least one pipe on every pipe machine before we ship out.
Some of our heavy duty models works well after even 7 or 8 years according to our client feedback, for all of our machine we offer 12 month warranty.
3. WHAT CAN YOU BUY FROM US?
All kind of pipe tools and plumbing tools, such as pipe threading machine, pipe grooving machine, pipe cutting machine, pipe hole cutter, manual pipe bender, pipe vice as well as the test pump.
4. WHY SHOULD YOU BUY FROM US NOT FROM OTHER SUPPLIERS?
We focus on quality piping tools, machinery and service. We have almost all kind of pipe tools, place order to us we can mix different models in one shipment. Language available:English,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
5. HOW LONG IS THE LEADTIME?
Since the voltage of machine motors are customized, usually the lead time will be 10-35 days after payment.
6. HOW CAN YOU PLACE ORDER?
We accept T/T payment directly to our company account and we can also create order on the online shop site that you can pay to us by credit card.
7. HOW TO SHIP?
We ship by sea to port for bulk order and we also ship to door for small shipment.
8. WHAT IS THE MOQ?
Basically there is no MOQ required for our machines, we can ship any quantity but it is highly recommened to make order amount not less than USD2000.00, because according to our experience if the order are too small amount the sea shipping adding tarrif makes it not cost-effective to buy oversea.
9. IS OEM ACCEPTABLE?
Yes. For bulk order we can make nameplate and customized packaging in client’s brand.

Suntech Machinery is a professional company of pipe machine for more than 20 years, Mainly for Pipe Threading Machine, Pipe Cutting Machine, Roll grooving machine, HDPE Butt Fusion Welding Machine, Socket Welding Machine and Relate Manual Tools. We are located in Hangzhou city of China.
From metal pipes to plastic pipes, we offer a wide variety of plumbing tools for on-site working. Our machines have already been exported to many countries and are widely known for its durability and quality. We also offer customization as per the specifications detailed by our clients to fulfill their needs and requirements. We are looking forward to enjoy sincerely cooperation with more and more friends over the world.
