This hydraulic roll groover equips with updated hydraulic pump, with convenient depth adjusting function, powered by 750w induction motor, is capable of grooving 1''-6'' pipes. Separate knurling roller design of drive shaft for convenient replacement.

● This machine is designed for automatic production line of steel pipes.
● Electrical system and hydraulic system are controlled by computer with touch screen.
● Achieve 100% automatic production after assembled with the steel pipe production line.
● Output RPM of spindle is variable for different steel pipes, the efficiency greatly improved.
● The full production line offer automatic pipe feeding.

Specifications
Model: STG4Z
Capacity: 8"-24"(φ219-φ630mm diameter)SCH40 steel pipe
Max. wall thickness: 13mm
Motor power: 2200W 3PH
Output RPM: 15rpm
G.W.:490kgs
Packaging size: 107x85x168cm
98x98x63cm

Standard Equipment
*For SCH40 steel pipe
Knurl wheel φ219-325
Knurl wheel φ377-426
Knurl wheel φ480-630
Pinch roller φ219-530
Pinch roller φ630
Pipe stand

Foot switch

PICTURES FOR ROLL GROOVER MACHINE 8''-24''

OPERATION OF ROLL PIPE GROOVING MACHINE
Choose the right pinch roller and knurl wheel and install them onto the roll grooving machine.
Put the pipe on the knurl wheel and pipe stands. The pipe stands should be placed at the position of 3/4 length of pipe. Then adjust the pipe stands height to make sure the pipe are 1 degree lower than the horizantal level.
Tighten the relief valve, shake the hydraulic pump handle, let the pinch roller going downward until it touch the surface of pipe end. Rotate the limit nut down, make it contact with the oil pump top frame. Check the correct data of groove depth for different diameter pipes in the chart. For instance, if we roll groove on a 8 inch pipe, the depth will be 2.34mm. Calculate from the red start line, rotate the limit nut 2.34mm up, then turn the fastening nut down until it touch the limit nut and fix it. (One circle rotation on the limit nut is equal to 2.5mm) Rotate the side guide wheel to support the pipe. Release the relief valve.
Connect the power plug, turn on the switch to run the machine. Tighten the relief valve again and pump the handle to start grooving. Continue to swing the handle until the limit nut reach the oil pump top (Please do not swing too fast). Allow the pipe to rotate additional one or two turns to make sure the groove is completed. At last turn off the switch and release the relief valve knob. Rotate the guide wheel to make it away from the pipe. Remove the pipe and check the groove depth with a pipe groove measuring tape.

Roll grooving machine is a kind of pipe tool for workers to make groove then connect pipe by using grooved joints such as couplings.
The principle of grooving machine is hard extrusion, when the upper roller touches the pipe surface, turn on the motor, handle the hydraulic oil pump to make the pipe rotate. The upper roller can press the pipe by shaking the handle of hydraulic oil pump, then form a groove. Roll grooving machine is widely used in fire-fighting system, Sprinkler systems, installations, larger heading units, industrial use and mining. The grooving machine is characterized by compact structure, flexible operation and beautiful shape.
